What this Ram 1500 diagram covers

This list is Moog’s Ram 1500 pages from the 2007–2018 book: 2011–2018 DS (4th gen) plus 2019 1500 Classic. The PDF’s first page still has leftover Porsche Macan rows; those are not used here. 2019+ 5th-gen (DT, Rebel, TRX) is a different front end. Do not mix 1500 IFS numbers with Ram 2500/3500 solid-axle steering.

On 2009–2018 1500s the parts that come up most often are upper and lower ball joints, outer tie rods, hub bearings, and sway-bar links. A clunk at low speed is usually a ball joint or sway link; wander or inner-edge tire wear is more often a tie rod or a worn control-arm bushing. Control arms are commonly replaced as complete units with the ball joint already pressed in.

Use the year/make/model search on this page, or pick the Moog number off the diagram and search it. Related: 2020 Ram 1500 5-inch lift kit and how to diagnose suspension noises.

Jump to: 2013–2018 · 2011–2012 · 2019 Classic · Steering · Rear · Catalog diagrams

2013–2018 Ram 1500 (DS, 4th gen)

4×4 and 4×2 air-suspension trucks share a lot of the front end. Coil-spring 4×2 uses different lower arms. Do not mix these with Ram 2500/3500 solid-axle numbers, and do not use them on 2019+ 5th-gen (DT) trucks except the Classic listed below.

Ball joints

• Upper (adjustable, ±2.25° camber/caster): K100316 — 2013–2018
• Upper Problem Solver (±3°, greaseable): K100115 — 2013–2018
• Lower, press-in, 4×4: K500286 — 2013–2018
• Lower, press-in, 4×2 with air suspension: K500286 — 2013–2018

Control arm bushings

• At shock (split, 4×4 / 4×2 air): K200688
• Lower rear (4×4): K200184
• Lower front (4×4): K200185

Control arms with ball joint

• Lower, 4×4 or 4×2 air, R-Series: left RK641504, right RK621602
• Upper, forged, coil-spring: left RK620634, right RK621897
• Lower, 4×2 coil-spring: left RK623101, right RK623100
• Upper, stamped, air suspension: RK643074

Strut, mount, sway bar

• Strut/spring/mount assembly, 4×4 except air (2011–2015): ST8606
• Strut bumper bellows, 4×4 except air: K201301
• Strut bushing, lower, 4×4: K160326
• Strut mount with spring seat, 4×4 except air: K160196
• Sway bar to frame, 4×4, 32mm improved: K201621 — or standard K7353
• Sway bar to frame, 4×4, 36.8mm: K7384
• Sway bar link (2013–2017): K80894
• Wheel hub (2012–2018): 515151

2011–2012 Ram 1500

Same DS truck, but 5-lug vs 8-lug and 4×2 vs 4×4 change the lower arms, inners, and hubs. 8-lug 4×2 uses the older F335 layout.

• Upper ball joint: K100316 or Problem Solver K100115
• Lower, 4×4 press-in: K500286
• Lower, 4×2 5-lug: K7411
• Upper arm 8-lug (with bushings): CK620181 or R-Series RK620181
• Lower, 4×2 5-lug: left RK6415040, right RK6415041
• Lower, 4×2 8-lug: left RK6415042, right RK6415043
• Upper bushing kit 8-lug: K200115 — lower bushing 4×2 8-lug: K200114
• Sway link 4×2: K808942 or K808943 — 4×4: K80894
• Sway repair bushing kit: K7300
• Hub, 2011 5-stud: 5151512 — 2012+ : 515151

2019 Ram 1500 Classic

Classic is the old DS body still sold next to the 2019+ 5th-gen. These numbers match the 2013–2018 4×4 list, not the new DT truck.

• Lower ball joint, 4×4: K500286
• Lower arm, 4×4: left RK641504, right RK621602
• Shock bushing: K200688
• Sway bar to frame 24mm: K3170 — 32mm: K201621 or K7353 — 36.8mm: K7384
• Sway link: K80894

Steering (tie rods)

• 2013–2019 Classic outer: ES801123 — inner: EV800958
• 2011–2012 5-lug outer: ES80574 — inner: EV800098
• 2012 8-lug inner: EV80211

Rear suspension

• Upper control arm, 2013–2019 Classic: RK642932 — 2011–2012: RK642211
• Lower control arm, 2011–2012: RK643104
• Rear sway bar link, 2011–2019 Classic: K750396
• Track bar, 2011–2019 Classic: RK661215

Figures F335, F338, F339, F600, S094, and S322 are in the catalog PDF below. The first PDF page also has leftover Porsche Macan rows from the Moog book; ignore those.

If your year is newer than the catalog, use the year/make/model search on this page. Leave a comment with the year and the noise if you want a part-number check.
