Moog Parts for Ford F-150 (1990 & Prior)
Front Suspension
Ball Joint
| Year | Model/Application | Part | Qty | Figure |
|---|---|---|---|---|
| 1990-1980 | Powdered Metal Gusher Brg. For Better Lubrication | K8008 ‡ | 2 | F121 |
| 1979-1973 | Powdered Metal Gusher Brg. For Better Lubrication | K8008 ‡ | 2 | F121 |
| 1972-1967 | K8008 ‡ | 2 | F121 |
Control Arm Bushing
Find the Suspension Parts you Need
| Year | Model/Application | Part | Qty | Figure |
|---|---|---|---|---|
| 1990-1980 | Upper | K8064 | 2 | F121 |
| 1990-1980 | Lower | K8059 | 2 | F121 |
| 1979-1973 | Upper | K8064 | 2 | F121 |
| 1979-1973 | Lower | K8059 | 2 | F121 |
Additional Front Suspension Parts
- Radius Arm Bushing Kit: K8058 (1990-1980)
- Strut Rod Bushing: K8058 (1990-1980)
- Sway Bar Bushing (To Frame): K8115 (1990-1980)
- Sway Bar Repair Kit: K700012 (1990-1980)
Steering
| Year | Part | Side | Part Number | Qty | Figure |
|---|---|---|---|---|---|
| 1990-1980 | Idler Arm | — | K8063 ‡ | 1 | S201 |
| 1990-1980 | Pitman Arm | — | K8062 | 1 | S201 |
| 1990-1980 | Tie Rod Adjusting Sleeve | — | ES2032S | 2 | S201 |
Tie Rod Ends
Rear Suspension
- Leaf Spring Bushing (Front): K200958 (1990-1973)
- Leaf Spring Shackle Bushing: K3194 (1990-1980, Upper)
- Leaf Spring Shackle Bushing: K8785 (1990-1980, Lower)
