Looking for a suspension diagram, kit, or repair guide to diagnose and fix your Toyota RAV4 suspension noise or other problem? Look no further! We’re also happy to help you figure out what parts you need, just post a comment below with the year make and model and the problem you are encountering and we can guide you with the suspension kit, upgrade, or part numbers you need. #HAPPYMOTORING
Search and buy these parts on Amazon
Find the Suspension Parts you Need
Jump to: Front · Steering · Rear · Catalog diagrams
Front suspension
Ball joints
- Lower, bolt-on, 2018–2006: K500062
Control arms with ball joint
Strut bumper bellows
- Original Equipment Type, 2018–2013: K201415
- 2018–2006: K90461
- Original Equipment Type, 2010–2006: K201415
Strut mounts
Sway bar bushings
- To frame, 2012–2009: K201279
- To frame, Except Third Row Seating, 2008–2007: K201482
- To frame, Third Row Seating, 2008–2006: K201279
Sway bar links
Wheel hubs & bearing assemblies
Steering
Tie rod ends
- Outer, 2.5L, 2018: left ES800054, right ES800053
- Outer, 2017–2006: left ES800054, right ES800053
- Inner, Gasoline, 2012: EV800328
- Inner, 2011–2006: EV800328
Rear suspension
Control arms
- Upper, +/- 3 Degrees Camber, Greaseable, Turnbuckle Adjustment, 2018–2006: left RK100356, right RK100357
- Upper, +/- 3 Degrees Camber, Non-Greasable, Eccentric Adjustment, 2018–2006: left RK100354, right RK100355
- Upper, 2017–2006: left RK641740, right RK641739
- Rear lower, Except Japan Built, Thru 6/14, 2014: left RK641939, right RK641938
- Rear lower, Thru 9/14, Japan Built, 2014: left RK641939, right RK641938
- Rear lower, 2013–2006: left RK641939, right RK641938
Control arms with ball joint
- Lower front, North American Built – 1st Digit Of VIN 1, 2 Or 4, 2018–2011: RK621848
- Lower front, +/- 3 Degree Toe, Adjustable, 2010–2006: RK100170
Sway bar bushings
- To frame, Split Design, 2012–2006: K200829
Sway bar links
- 2018–2006: K750257
Wheel hubs & bearing assemblies
Figures F366, S185, R192 are in the catalog PDF below. The PDF also has leftover Toyota Land Cruiser, RAV4 EV, and Toyota Sequoia rows from the Moog book; ignore those.
