Need 2018 Chevy Silverado 1500 ball joints, control arms, hubs, or a front-end kit? 2018 is K2XX Silverado 1500 (2014–2018). Aluminum vs steel knuckles and cast-iron vs aluminum arms change the lower ball joint and arms. This is not 2019+ (T1), not 2500/3500, and not Suburban.
A clunk at low speed is usually a ball joint or sway link. Wander or inner-edge tire wear is more often a tie rod or a worn control-arm bushing. Most people replace the control arm as a complete unit with the ball joint already pressed in.
Find the Suspension Parts you Need
Other years: 2007 · 2008 · 2009 · 2010 · 2011 · 2012 · 2013 · 2014 · 2015 · 2016 · 2017 · 2018
Search and buy 2018 Chevy Silverado 1500 parts on Amazon
Jump to: Shop notes · Works Kit · Front · Steering · Fitment notes
Leveling the rake? Compare ReadyLIFT, Rough Country, and Daystar 2″ kits for this generation: 2014–2018 Chevy Silverado 1500 2 Inch Leveling Kit.
GMT K2XX Silverado 1500 (2014–2018) shop notes — 2018
2018 Chevy Silverado 1500 suspension — K2XX shop focus
Model-year 2018 sits in the K2XX Chevy Silverado 1500 window (2014–2018). It is not 2500/3500 HD.
Catalog applications for K2XX (2014–2018) often repeat the same SKUs across adjacent years in this generation — that is expected. This URL stays year-specific for 2018 with a self-canonical and year-locked heading/links. On-page catalog SKUs called out here include MOOG front, MOOG K500340, MOOG ES800948, MOOG EV800938, MOOG CK620956, MOOG RK620888, MOOG K201612, MOOG K200221 — use only these rows (and the lists below), not torque charts we do not publish. Cross-shop the same model year: 2018 Chevy Silverado 1500 brake parts.
These are shop notes for the GMT K2XX Silverado 1500 (2014–2018) that includes 2018. Do not mix GMT900 (2007–2013) arms/hubs.
What usually brings people here
- Low-speed clunk over bumps or driveways → ball joint or sway link (K500340). Most shops prefer replacing the control arm as a complete unit with the joint already pressed in.
- Wander, loose steering feel, or inner-edge tire wear → outer/inner tie rod (ES800948 / EV800938) or a worn control-arm bushing.
- Growl or rumble that rises with road speed → wheel hub/bearing (515160).
Key SKU choices
Upper ball joint on this page: K500340. Match the arm style (forged vs stamped / aluminum vs iron) before you order — the wrong upper is a common return.
Outer/inner tie rods on this page: ES800948 / EV800938. Replace as a pair when play is present; an alignment is required after tie-rod work.
Fitment forks on this page
- lower, 4×4, Except Off Road Package, cast iron arm, not aluminum knuckle: CK620956
- lower, 4×4, Except Off Road Package, cast iron arm, not aluminum knuckle: RK620888
- lower, 4×2, Except Off Road Package, cast iron arm, not aluminum knuckle: CK620956
- lower, 4×2, Except Off Road Package, cast iron arm, not aluminum knuckle: RK620888
- lower, 4×2, cast iron arm, not aluminum knuckle: CK620956
- lower, 4×2, cast iron arm, not aluminum knuckle: RK620888
While you’re in there
While you’re tearing into the front end, inspect the matching side and the sway-bar links — one-sided wear is common after a hit or a long alignment delay. Confirm the hub (515160) if you have a growl that rises with road speed.
Shop notes only — not a service manual. Use the factory procedure or a Haynes/Chilton manual for wrench work, torque, and safety steps. Leave a comment with drivetrain, suspension type, and the symptom if you want a part-number check.
Works Kit — 2018 Chevy Silverado 1500 front-end (K2XX 2014–2018 · not 2500/3500 HD · aluminum vs cast-iron knuckle)
SKU-grounded 2018 kit (not a year-clone blurb): upper/clunk K500340, then ES800948 outers + EV800938 inners, then 4×4 hub 515160. Tear-down tip for 2018: photograph fastener orientation, then buy the full stack so you are not waiting on a second order. order it all once, do it right. Sway/frame bushing length callouts include K201612.
1. Clunk / sway kit
2. Wander / tire-wear kit (both sides)
3. Hub growl add-on
- Wheel hub/bearing — 515160
Search Amazon for a 2018 Silverado 1500 front-end kit · Full lists are below.
2018 Chevy Silverado 1500 front suspension
Ball joints
- Upper: K500340
Control arms with ball joint
- Left lower, 4×4, Except Off Road Package, cast iron arm, not aluminum knuckle: CK620956
- Left lower, 4×4, Except Off Road Package, cast iron arm, not aluminum knuckle: RK620888
- Left lower, 4×2, Except Off Road Package, cast iron arm, not aluminum knuckle: CK620956
- Left lower, 4×2, Except Off Road Package, cast iron arm, not aluminum knuckle: RK620888
- Left lower, 4×2, cast iron arm, not aluminum knuckle: CK620956
- Left lower, 4×2, cast iron arm, not aluminum knuckle: RK620888
Sway bar bushings
- To frame, 34mm Sway Bar Diameter: K201612
- To frame, 34mm Sway Bar Diameter, standard: K200221
- To frame, 36mm Sway Bar Diameter, standard: K200222
Wheel hubs & bearing assemblies
- 4×4: 515160
2018 Chevy Silverado 1500 steering
Tie rod ends
Fitment notes
These Moog numbers come from the 2007–2018 catalog rows that include 2018. Confirm 4×2 vs 4×4, aluminum vs steel, and trim before you order.
Diagrams are on the Silverado 1500 catalog page. Related: Silverado kit page. How to diagnose suspension noises.
Leave a comment with 4×2 vs 4×4 and the noise if you want a part-number check. #HAPPYMOTORING
